                Inhouse product
Power supplies - Phaseo ABL7, ABL8
Single phase and 3-Phase power supplies, 100 V to 500 V - 7 W to 960 W
Transformers - Phaseo ABT7, ABL6
230 V to 400 V - 25 VA to 2500 VA
| Technical Spec | Schneider |
| Product Model | Phaseo Optimum |
| Product type | Voltage transformer |
| Rated power in VA | 400 VA |
| Input voltage | 230 V AC single phase, terminal(s): N-L1 400 V AC phase to phase, terminal(s): L1-L2 |
| Network frequency | 47...63 Hz |
| Output voltage | 24 V AC |
| Secondary winding | Single |
| Protective cover | Without |
| Power dissipation in W | 34.8 W |
| No load losses | 12.4 W |
| Voltage drop at rated load | 0.5 % |
| Output protection type | Against overload, protection technology: external Against overvoltage, protection technology: external Against short-circuits, protection technology: external |
| Line and load regulation | 1...3 % |
| Height x Width x Depth | |
| Product weight | 6.5 kg |
| Standards | UL 508 UL 506 |
| Warranty period | 12 month |
