Hantek DSO2D15 150MHz 2-Channel Digital Storage Oscilloscope with 1GSa/s Sampling Rate & Built-in Waveform Signal Generator

The Hantek DSO2D15 is a high-performance digital storage oscilloscope (DSO) designed for professional engineers, technicians, and electronics enthusiasts. Featuring a 150MHz bandwidth, 1GSa/s real-time sampling rate, and 2 independent channels, this oscilloscope provides precise and reliable waveform analysis for a wide range of applications, including circuit design, troubleshooting, and signal analysis. Additionally, it includes a built-in waveform signal generator, making it a versatile tool for testing and development.

Key Features & Specifications

? 150MHz Bandwidth & 1GSa/s Sampling Rate

• Provides high-speed, accurate waveform capture for detailed signal analysis.
• Supports real-time and equivalent-time sampling modes.

? 2-Channel Input

• Allows simultaneous signal measurement on two independent channels for efficient troubleshooting.

? Built-in 25MHz Arbitrary Waveform Generator (AWG)

• Generates standard and custom waveforms for circuit testing and simulation.

? Large 7-Inch TFT LCD Display (800×480 Resolution)

• High-resolution color screen with a user-friendly interface for clear and detailed waveform visualization.

? Advanced Triggering System

• Supports Edge, Pulse, Video, Slope, and Alternative triggering modes for precise signal capture.

? Deep Memory Depth (8Mpts)

• Enables extended waveform recording and detailed signal analysis.

? Multiple Math & Measurement Functions

• Includes FFT analysis, addition, subtraction, multiplication, and division for in-depth waveform examination.

? USB Connectivity & PC Software Support

• Easily transfer data, save waveforms, and analyze signals using the included PC software.

? Compact & Durable Design

• Portable and robust construction suitable for both laboratory and fieldwork applications.

Ideal Applications

✅ Electronic circuit design & testing
✅ Embedded system development
✅ Power supply & signal analysis
✅ Automotive diagnostics
✅ Communication system troubleshooting
✅ Education & research laboratories

The Hantek DSO2D15 is a powerful and cost-effective oscilloscope that combines high precision, multiple functionalities, and ease of use, making it an essential tool for engineers, technicians, and students working with electronic circuits and signal analysis.
