CP-180 Hydraulic pedal pump

1.pressure rating: 0-600 kgf/cm2

2.Reservoir capacity：400cc

3.size: 340x130x100mm

4. weight: 3.6 kg

CP-390 Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 9.8L/min, high 1.9L/min

4.Reservoir capacity：400cc

5.size: 430x105x160mm

6. weight: 4.6 kg

CP-700 Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 12.26L/min, high 2.26L/min

4.Reservoir capacity：900cc

5.size:510x630x150mm

6. weight: 9.2 kg

CP-700-2A Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 12.26L/min, high 2.26L/min

4.Reservoir capacity：1900cc

5.size:630x240x140mm

6. weight: 12.22 kg

CP-700D Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 9.8L/min, high 1.9L/min

4.Reservoir capacity：3000cc

5.size:430x105x160mm

6. weight: 12 kg

HP-700A Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 12.26L/min, high 2.26L/min

4.Reservoir capacity：900cc

5.size:545x170x185mm

6. weight: 8 kg

CFP-800 Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 13L/min, high 2.3L/min

4.Reservoir capacity：700cc

5.size:250x140x250mm

6. weight: 14 kg

CFP-800-1 Hydraulic pedal pump

1.Max pressure rating: 700/10000 kgf/cm2/psi

2.pressure rating: low 0-20, high 20-700 kgf/cm2

3.Oil delivery：low 9.8L/min, high 1.9L/min

4.Reservoir capacity：610cc

5.size:460x150x240mm

6. weight: 9.6 kg
