MAL Series Mini Cylinder

The MAL Series Mini Cylinder is a compact and versatile pneumatic actuator designed for applications requiring precision, space-saving design, and reliable performance. These cylinders are perfect for automated systems, offering smooth linear motion and high efficiency in small-scale operations.

Key Features:

1. Compact and Lightweight Design:

   • The MAL Series cylinders are designed for installations with limited space, ensuring easy integration into various systems.

2. Durable Construction:

   • Made with an aluminum alloy body for lightweight strength and corrosion resistance.
   • Stainless steel piston rods enhance durability and resistance to wear.

3. Double-Acting Operation:

   • Allows for efficient bidirectional movement, suitable for a wide range of industrial tasks.

4. Wide Range of Bore Sizes:

   • Available in bore sizes from 16mm to 40mm, catering to diverse application requirements.

5. Adjustable Stroke Length:

   • Offers stroke lengths customizable to the needs of the specific operation, typically ranging from 10mm to 300mm.

6. Air Cushion Design:

   • Provides smooth operation by reducing the impact at the end of each stroke, minimizing wear and prolonging the cylinder's lifespan.

7. Versatile Mounting Options:

   • Includes threaded end caps and mounting brackets for flexible installation.

8. Efficient Sealing:

   • Equipped with high-quality seals to prevent air leakage and ensure consistent performance.

Technical Specifications:

Applications:

The MAL Series Mini Cylinder is widely used in:

• Automation Systems: Ideal for small machinery and robotic applications.
• Electronics Manufacturing: Precise handling and assembly processes.
• Textile Industry: Actuation in compact and high-speed machinery.
• Packaging: Lightweight operations such as labeling, cutting, or pushing.

Advantages:

• Space-Efficient: Compact size fits perfectly in limited spaces.
• High Performance: Provides smooth, accurate, and reliable linear motion.
• Customizable: Multiple configurations available to meet specific operational needs.
• Cost-Effective: Economical solution for small-scale pneumatic applications.
