A transformer bushing is a critical insulating component designed to safely carry high voltage current through the grounded tank of a transformer. It provides an insulated path for electrical conductors to pass through grounded barriers without compromising dielectric performance or structural integrity. Used in both power and distribution transformers, transformer bushings are essential for efficient energy transfer and system reliability.

Engineered for high mechanical strength and excellent thermal endurance, transformer bushings are typically manufactured using porcelain, epoxy resin, or a composite polymer material. They are available in oil-filled, resin-impregnated, or dry-type configurations, suitable for a range of indoor and outdoor transformer applications.

These bushings are built to withstand environmental stress, electrical surges, and mechanical loads, while ensuring minimal partial discharge and high insulation resistance. Available in a variety of voltage ratings and mounting configurations, transformer bushings are compatible with international standards such as IEC, ANSI, and IS.

 Features:

• Provides electrical insulation for high-voltage terminals

• Manufactured from porcelain, epoxy resin, or composite materials

• Available in oil-filled, dry-type, and resin-impregnated paper (RIP) designs

• High mechanical and dielectric strength

• Designed to handle internal pressure and thermal fluctuations

• Suitable for both indoor and outdoor transformer applications

• Resistant to environmental conditions and electrical stress

• Complies with IEC, ANSI, and IS standards

Applications:

• Power transformers

• Distribution transformers

• Switchgear and substations

• Renewable energy systems

• Industrial and utility power networks

Technical Specifications:

Specification Details
Material Porcelain, epoxy resin, or polymer composite
Bushing Type Oil-filled, dry-type, RIP (resin-impregnated paper)
Voltage Rating 1 kV to 400 kV (customizable)
Creepage Distance As per pollution class and standard requirements
Mounting Type Flange-mounted or draw-lead type
Insulation Level High dielectric and insulation resistance
Standard Compliance IEC 60137, ANSI/IEEE C57.19.00, IS 2099
Application Environment Indoor or outdoor use
