The Sinometer UT101 is an automotive tester and digital multimeter flawlessly combined into one, it can measure AC/DC voltage, DC current, resistance as well as diode check and continuity test. For automotive testing, you can use it to measure dwell angle and RPM up to 10,000.

Specifications:

DC Voltage: 200 mV, 2V, 20V, 200V ±0.5% 1000V ± 0.8%, Impedance: 10 M ohm
AC Voltage: 2V/20V/200V ±0.8%, 750V ± 1.2%, Impedance: 10 M ohm
DC Current: 20mA ± 0.8% / 200mA ± 1.5% / 10A ± 2.0%
AC Current: 200mA ± 1.8% / 10A ± 3.0%
Resistance: 200 ohm, 2K ohm, 20K ohm, 200K ohm ± 0.8% 20M ohm ±1.0%
Diode Test
hFE
Continuity Test
Tachometer: 180 to 10,000 RPM ±3.0% (3, 4, 5, 6, and 8 Cylinder)
Dwell: 3, 4, 5, 6, and 8 Cylinder ±1.0%
Dimensions: 190 x 88 x 34 mm
Weight: 270 grams

Features:

Manual Range Control
Automatic Negative Polarity Indication
Low Battery Indicator
Over Range "1" Display

What's in the box:

UT101 Automotive tester
Test leads
9V battery (installed)
User manual

About this item

• All-around meter designed for automotive testing, trouble-shooting & household electrical problems
• AC/DC Voltage, AC/DC Current 10A, Resistance, Continuity, Diode & Transistor Check
• Dwell angle & tachometer measurement, number of cyclinders selectable, 3/4/5/6/8
• Diode, Resistance and Continuity Test
• One-year manufacturer's warranty
