CJ2B Series Mini Cylinder

The CJ2B Series Mini Cylinder is a compact and lightweight pneumatic actuator designed for precise and efficient performance in limited spaces. Engineered with high-quality materials and innovative design, it is ideal for applications that require reliable operation and compact dimensions.

Key Features:

1. Compact Design:

   • Small and lightweight, suitable for installation in tight spaces.
   • Ideal for automation tasks with size constraints.

2. Double-Acting Operation:

   • Provides smooth and controlled motion in both forward and backward directions.
   • Ensures reliable performance for various applications.

3. High Durability:

   • Constructed from robust aluminum alloy, ensuring corrosion resistance and longevity.

4. Wide Range of Bore Sizes and Strokes:

   • Available in multiple sizes to accommodate different load and motion requirements.

5. Efficient Sealing System:

   • High-quality seals prevent air leakage and ensure consistent pneumatic performance.

6. Ease of Installation:

   • Designed for simple and fast mounting with various mounting options available.

7. Cushioning Capability:

   • Built-in cushioning for smooth operation and reduced impact at the stroke ends.

Specifications:

• Bore Sizes: Ranges from 6mm to 16mm.
• Stroke Lengths: Customizable up to 200mm, depending on the bore size.
• Operating Pressure: 0.1 to 0.7 MPa.
• Fluid Medium: Air (filtered to 40 µm).
• Temperature Range: -10°C to 60°C.
• Port Size: Compatible with standard pneumatic fittings for seamless integration.

Applications:

The CJ2B Series Mini Cylinder is widely used in industries such as:

• Electronics Manufacturing: For precise positioning and assembly tasks.
• Automated Equipment: Ideal for pick-and-place, sorting, and light-duty tasks.
• Packaging Machines: Used in compact systems for sealing, cutting, and labeling.
• Medical Equipment: Supports delicate and precise motion control.
• Laboratory Automation: Perfect for tasks requiring minimal space and high precision.
