MR Type Current Transformer Unit

Features:

• The accuracy class ensures minimal percentage error at the rated current specified for each class, maintaining high measurement precision.
• Electronic Transformers utilize a standard silicon steel core construction with tape-wrapped design, offering an economical solution for current transformation.
• These measuring transformers can be equipped with or without a base mount and plastic casing, enhancing flexibility for various setups.

Applications:

• Ideal for current measurement, monitoring, and protection of electrical circuits and equipment.
• Suitable for power and current measurement across electric motors, lighting, HVAC systems, air compressors, heating units, and automated controls.
• Perfect for power, current, and energy monitoring devices as well as relay protection systems.

Specifications:

• Frequency: 50/60 Hz
• Rated Input: 30A to 5000A
• Rated Output: 1A or 5A
• Measurement Range: 5%In to 120%In
• Rated Voltage: 0.72 kV (AC)
• Dielectric Strength: 3.0 kV / 1mA for 1 minute
• Insulation Resistance: Min. 100MΩ at DC500V
• Case Material: PC / UL94-V0
• Bobbin Material: PBT
• Core Material: Silicon steel
