OU Series FRL Combination

The OU Series FRL Combination offers a versatile and efficient solution for air preparation by integrating filtration, regulation, and lubrication functions into a single compact unit. Designed for optimal performance, it is ideal for various pneumatic applications where clean, regulated, and lubricated compressed air is essential.

Key Features:

1. Comprehensive Functionality:

   • The OU filter regulator lubricator combines an OFR filter regulator and an OL lubricator, which can also be ordered and used separately.

2. Effective Filtration:

   • The OFR filter with a built-in water separator removes oil, condensation, and dirt particles from compressed air.
   • Comes with a standard 40μm filter element, replaceable with a 5μm filter element for specialized applications.

3. Reliable Pressure Regulation:

   • The OR regulator ensures a constant operating pressure, unaffected by fluctuations in line pressure or air consumption.

4. Precision Lubrication:

   • The OL lubricator provides a regulated oil-mist supply proportional to the air flow.
   • Features an adjustable bolt for controlling the oil drip-rate, with the ability to add oil during operation.

5. User-Friendly Design:

   • Compact integration of compressed air filter, regulator, and lubricator.
   • Available with manual or semi-automatic condensate drain for easy maintenance.

Specifications:

• Model: OU-MIDI
• Brand: VPC Pneumatic
• Code: 8421399000
• Working Medium: Compressed air
• Mounting Type:
  • Pipe mounting
  • Leg mounting
• Working Temperature: 0°C to 60°C
• Working Pressure:
  • 0.05 to 1.2 Mpa
  • 0.05 to 0.7 Mpa
• Assembly Position: Vertical ±5°
